Click the product type number for detailed information.
|
|
Side cut type : 172mm X Thick : 51mm |
|
|
Model No.
|
Rated Voltage (V) |
Rated current (A) |
Rated input (W) |
Rated speed (min-1) |
Air flow (m3/min) |
Static pressure (Pa) |
Noise (dB[A]) |
Mass (g) |
109E5712F501
|
12
|
0.68
|
8.16
|
2,500
|
5.1 (180CFM)
|
95 (0.38inchH2O)
|
47
|
760
|
109E5712H501
|
12
|
1.2
|
14.4
|
3,050
|
6.4 (226CFM)
|
137.2 (0.551inchH2O)
|
52
|
760
|
109E5712K501
|
12
|
2.9
|
34.8
|
4,100
|
8.5 (300CFM)
|
243.0 (0.976inchH2O)
|
60
|
760
|
109E5712M501
|
12
|
0.48
|
5.76
|
2,000
|
4.2 (148CFM)
|
67.6 (0.271inchH2O)
|
41
|
760
|
109E5712Y501
|
12
|
2.3
|
27.6
|
3,800
|
8 (282CFM)
|
210 (0.84inchH2O)
|
60
|
760
|
109E5724C501
|
24
|
2.3
|
55.2
|
4,800
|
9.9 (350CFM)
|
308.0 (1.237inchH2O)
|
66
|
760
|
109E5724F501
|
24
|
0.35
|
8.4
|
2,500
|
5.1 (180CFM)
|
95 (0.38inchH2O)
|
47
|
760
|
109E5724H501
|
24
|
0.58
|
13.92
|
3,050
|
6.4 (226CFM)
|
137.2 (0.551inchH2O)
|
52
|
760
|
109E5724K501
|
24
|
1.3
|
31.2
|
4,100
|
8.5 (300CFM)
|
243.0 (0.976inchH2)
|
60
|
760
|
109E5724M501
|
24
|
0.2
|
4.8
|
2,000
|
4.2 (148CFM)
|
67.6 (0.271inchH2O)
|
41
|
760
|
109E5748C501
|
48
|
1.2
|
57.6
|
4,800
|
9.9 (350CFM)
|
308.0 (1.237inchH2O)
|
66
|
760
|
109E5748F501
|
48
|
0.19
|
9.12
|
2,500
|
5.1 (180CFM)
|
95 (0.38inchH2O)
|
47
|
760
|
109E5748H501
|
48
|
0.28
|
13.44
|
3,050
|
6.4 (226CFM)
|
137.2 (0.551inchH2O)
|
52
|
760
|
109E5748K501
|
48
|
0.7
|
33.6
|
4,100
|
8.5 (300CFM)
|
243.0 (0.976inchH2O)
|
60
|
760
|
109E5748M501
|
48
|
0.11
|
5.28
|
2,000
|
4.2 (148CFM)
|
67.6 (0.271inchH2O)
|
41
|
760
| |
